Built-in dimensions: 700 x 500 mm.
Light opening: 585 x 404 mm.
Designed for roof thickness: 30-34 mm (installation kits for other thicknesses are available as an option).
Weight: 8.2 kg.
Safety ventilation: 150 cm2 in closed position.
Can be supplemented with sealing strip K02 BG1521 which eliminates ventilation.
Other:
• Hood with double glazing – fixed with the outer frame.
• K02-27A/B opens in three positions: fully open, half open, and bad weather position.
• K02-37A/B has a stepless crank.
• Blackout curtain and mosquito net are separately adjustable.
